Prolink DS-3307 Zigbee 3.0 Smart Door/Window Sensor
Description
DS-3307
Smart Zigbee Door/Window Sensor
Trigger lights and alarms, get timely notifications, and more based on door and window activities with DS-3307 Smart Zigbee Door/Window Sensor. Seamlessly integrate it into your smart home for enhanced convenience and efficiency.
Zigbee Hub is required.
Features
At a glance
Zigbee 3.0 protocol
Tamper alarm
Ultra-low power consumption
Tech Specs
|
Communication |
Zigbee 3.0 |
|
Voltage |
1.8 - 3.6V |
|
Power Requirement |
CR2032 Battery x 1 |
|
Standby Current |
< 4uA |
|
Alarm Current |
< 0.5mA |
|
Channel and Frequency |
11 - 26 @ 2.400 - 2.483GHz |
|
Induction Range |
< 15mm |
|
Wireless Standard |
IEEE 802.15.4 |
|
Antenna Type |
PCB antenna, antenna gain 1dBi |
|
LED Indicator |
Red |
|
Operating Temperature and Humidity |
0°C to +40°C; 20% to 85%RH |
|
Storage Temperature and Humidity |
0°C to +60°C; 0% to 90%RH non-condensing |
Dimensions
|
Dimensions |
Product 52.45mm x 26.5mm x 12.7mm (Main body) With packaging NA
|
Original: $13.20
-65%$13.20
$4.62Product Information
